Stereotaxic

Digital stereotaxic instrument is the most cost-effective, has all the characteristics of standard brain stereotaxic instrument, and in the original standard of brain stereotaxic instrument based on 3 d manipulator increased displacement sensor, LCD display and locator separate installation, make the X, Y, Z three axis are displayed on the side, users do not need to start to check the data before and after directly read the X, Y, Z mobile distance, than other related domestic digital display device is more efficient to save time, bringing great experimental reading process; Three-dimensional manipulator display any proofreading zero, according to the map to locate directly, avoid secondary readings and calculation, simplifies the process; Mobile distance reading accuracy of 0.01 mm, satisfies the requirement of higher experiment.
Stereotaxic instrument is neuroanatomy, neurophysiology, nerve pharmacology and the important research in the field of neurosurgery, such as equipment, used for the orientation of the structure of neural injection, stimulating, destruction, and guide the potential operations, such as animal model can be used for Parkinson's disease, epilepsy animal model establishment, brain tumor model, learning and memory, the brain neural stem cell transplantation, such as cerebral ischemia research. With the outside of the skull logo or other reference point of three-dimensional coordinate system, determines the location of the subcortical some nerve structure, in order to not under the direct exposure to the directional stimulation, destruction and injection drug, and guide the potential research.(manipulator can be high temperature disinfection)

1.     Feature

Technical indicators:
1, the locator have constant temperature function
2, the temperature control range: room temperature ~ 60 ℃
3, the accuracy of reading: 0.01 mm
4, display: LCD display (X, Y and Z axis)
5, the function keys: the zero key (CLR/SET), relative/absolute value (REL/ABS) : relative absolute figures, : (mm/mm/feet/inch), function keys (F/ENTER)
6, material: alloy material
7, size: 350 * 250 * 340 mm
8, 360 - degree rotation manipulator, oscillation amplitude of 180 degrees
9, counting accuracy: + / - 0.01 mm
10, the three dimensional precision of propeller: + / - 0.01 mm
11, promote travel in three dimensions: 80 mm
12, working power supply: 1.5 V
13, can be up and down, left, right, front and back, rotating etc. Precise positioning
14, temperature control range: room temperature ~ 60 ℃ (recommended 34 ~ 38 ℃)
15, working conditions: temperature 0 to + 40 ℃;< 80% relative humidity
16, the storage temperature: - 10 - + 60 ℃
17, weight: 5.5 kg
18, 1 the attached map of rats
